Internal thread end swivel swaged

제품 라인업 — Threads · Internal threads

Internal thread end swivel swaged

No.	ø	a	b	c	ø d1	ø d2	sw	kg
30857-0300-020	3	M5	83	20	10	8	8	0.0390
Further informations Diameter: 3 mm Weight: 0.0390 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30857-0300-035	3	M5	99	35	10	8	8	0.0450
Further informations Diameter: 3 mm Weight: 0.0450 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30857-0400-020	4	M6	83	20	10	8	8	0.0330
Further informations Diameter: 4 mm Weight: 0.0330 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30857-0400-035	4	M6	99	35	10	8	8	0.0390
Further informations Diameter: 4 mm Weight: 0.0390 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30857-0500-020	5	M6	105	20	13	10	11	0.0700
Further informations Diameter: 5 mm Weight: 0.0700 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30857-0500-035	5	M6	120	35	13	10	11	0.0790
Further informations Diameter: 5 mm Weight: 0.0790 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30857-0600-025	6	M8	110	25	13	10	11	0.0710
Further informations Diameter: 6 mm Weight: 0.0710 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30857-0600-050	6	M8	135	50	13	10	11	0.0790
Further informations Diameter: 6 mm Weight: 0.0790 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
