Eyelet Webnet self-assembly for one rope

제품 라인업 — Webnet · Additional parts

Eyelet Webnet self-assembly for one rope

No.	ø	b	h	k	ø d	kg
30880-0100-02	1	13	5	2	2	0.0010
Further informations Diameter: 1 mm Weight: 0.0010 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30880-0150-02	1.5	16	8.3	3	3	0.0026
Further informations Diameter: 1.5 mm Weight: 0.0026 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30880-0200-02	2	20	10	3	4.5	0.0049
Further informations Diameter: 2 mm Weight: 0.0049 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30880-0300-02	3	30	14	5	5	0.0134
Further informations Diameter: 3 mm Weight: 0.0134 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
