Eyelet Webnet self-assembly for two ropes

제품 라인업 — Webnet · Additional parts

Eyelet Webnet self-assembly for two ropes

No.	ø	b	h	k	ø d	kg
30880-0100-01	1	13	5	2	2	0.0009
Further informations Diameter: 1 mm Weight: 0.0009 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30880-0150-01	1.5	16	8.3	3	3	0.0025
Further informations Diameter: 1.5 mm Weight: 0.0025 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30880-0200-01	2	20	10	3	4.5	0.0038
Further informations Diameter: 2 mm Weight: 0.0038 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30880-0300-01	3	30	14	5	5	0.0134
Further informations Diameter: 3 mm Weight: 0.0134 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
