Hook Webnet flat swaged for two ropes

제품 라인업 — Webnet · Additional parts

Hook Webnet flat swaged for two ropes

No.	ø	b	g	ø d1	ø d2	kg
31880-0150-12	1.5	38	14	5	17	0.0120
Further informations Diameter: 1.5 mm Weight: 0.0120 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
31880-0150-15	1.5	50	22	5	26	0.0160
Further informations Diameter: 1.5 mm Weight: 0.0160 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
31880-0200-12	2	42	14	6	17	0.0180
Further informations Diameter: 2 mm Weight: 0.0180 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
31880-0200-15	2	54	22	6	27	0.0240
Further informations Diameter: 2 mm Weight: 0.0240 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
