Hook Webnet with hole

제품 라인업 — Webnet · Additional parts

Hook Webnet with hole

No.	ø	b	g	ø d1	ø d2	ø d3	kg
30880-0150-13	1.5	38	14	5	17	2.5	0.0120
Further informations Diameter: 1.5 mm Weight: 0.0120 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30880-0150-16	1.5	50	22	5	26	2.5	0.0160
Further informations Diameter: 1.5 mm Weight: 0.0160 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30880-0200-13	2	42	14	6	17	3.5	0.0190
Further informations Diameter: 2 mm Weight: 0.0190 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30880-0200-16	2	54	22	6	27	3.5	0.0240
Further informations Diameter: 2 mm Weight: 0.0240 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
