Webnet

제품 라인업 — Webnet · Webnet with sleeves

Webnet
No. ø MW ML kg
20256-0300-040 3 40 74.8 3.4000
20256-0300-050 3 50 90.5 2.5600
20256-0300-060 3 60 106 2.0300
20256-0300-070 3 70 124 1.6400
20256-0300-080 3 80 141 1.3900
20256-0300-100 3 100 175 1.0500
20256-0300-120 3 120 209 0.8500
20256-0300-140 3 140 244 0.7760
20256-0300-160 3 160 279 0.6710
20256-0300-180 3 180 313 0.5770
20256-0300-200 3 200 346.18 0.4680
20256-0300-250 3 250 432.95 0.3670
20256-0300-300 3 300 519.38 0.3020
20256-0300-400 3 400 691.89 0.3020

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
