Webnet Micro

제품 라인업 — Webnet · Webnet with sleeves

Webnet Micro
No. ø MW ML kg
20261-0100-020 1 20 38.15 1.0600
20261-0100-025 1 25 45.39 0.7700
20261-0100-030 1 30 53.69 0.6100
20261-0100-035 1 35 61.5 0.5000
20261-0100-040 1 40 70.08 0.4800
20261-0100-050 1 50 87.14 0.3000
20261-0100-060 1 60 104.6 0.2300
20261-0100-070 1 70 121.46 0.1900
20261-0100-080 1 80 139.3 0.1600
20261-0150-025 1.5 25 45.46 1.8400
20261-0150-030 1.5 30 60.73 1.2800
20261-0150-035 1.5 35 67.98 1.2000
20261-0150-040 1.5 40 75.18 0.8500
20261-0150-050 1.5 50 91.39 0.6400
20261-0150-060 1.5 60 107.78 0.5000
20261-0150-070 1.5 70 124.78 0.4700
20261-0150-080 1.5 80 141.45 0.3400
20261-0150-100 1.5 100 175.34 0.3000
20261-0150-120 1.5 120 210.36 0.2400
20261-0150-140 1.5 140 244.98 0.2000
20261-0150-160 1.5 160 280.1 0.1700
20261-0150-180 1.5 180 314.33 0.1370
20261-0150-200 1.5 200 348.51 0.1300
20261-0150-250 1.5 250 435.6 0.1300
20261-0200-040 2 40 74.93 1.5400
20261-0200-050 2 50 91.11 1.1600
20261-0200-060 2 60 107.54 0.9200
20261-0200-070 2 70 124.1 0.7400
20261-0200-080 2 80 141.03 0.6500
20261-0200-100 2 100 175.16 0.4800
20261-0200-120 2 120 209.78 0.3700
20261-0200-140 2 140 244.11 0.3200
20261-0200-160 2 160 278.29 0.2700
20261-0200-180 2 180 313.2 0.2600
20261-0200-200 2 200 348.4 0.2100
20261-0200-250 2 250 435.2 0.1700

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
