Webnet sleeveless

제품 라인업 — Webnet · Webnet without sleeves

Webnet sleeveless
No. ø MW ML kg
20260-0150-025 1.5 25 44.61 0.8900
20260-0150-030 1.5 30 60.18 0.6900
20260-0150-040 1.5 40 74.76 0.5100
20260-0150-050 1.5 50 89.74 0.4100
20260-0150-060 1.5 60 105.66 0.3500
20260-0150-070 1.5 70 124.58 0.2900
20260-0150-080 1.5 80 139.56 0.2600
20260-0150-100 1.5 100 174.6 0.2100
20260-0150-120 1.5 120 208.48 0.1700
20260-0150-140 1.5 140 243.06 0.1500
20260-0150-160 1.5 160 277.75 0.1300
20260-0150-180 1.5 180 313.56 0.1200
20260-0150-200 1.5 200 349.88 0.1000
20260-0150-250 1.5 250 432.43 0.0800
20260-0200-040 2 40 74.8 0.9500
20260-0200-050 2 50 89.72 0.7700
20260-0200-060 2 60 105.72 0.6500
20260-0200-070 2 70 122.35 0.5500
20260-0200-080 2 80 139.57 0.4800
20260-0200-100 2 100 173.48 0.3900
20260-0200-120 2 120 207.52 0.3200
20260-0200-140 2 140 243.06 0.2800
20260-0200-160 2 160 276.27 0.2400
20260-0200-180 2 180 313.17 0.2200
20260-0200-200 2 200 346.8 0.1900
20260-0200-250 2 250 433.35 0.1600
20260-0300-040 3 40 73.86 2.3400
20260-0300-050 3 50 88.26 1.9100
20260-0300-060 3 60 105.66 1.6000
20260-0300-070 3 70 122.46 1.3600
20260-0300-080 3 80 139.49 1.1900
20260-0300-100 3 100 173.32 0.9600
20260-0300-120 3 120 207.26 0.8000
20260-0300-140 3 140 241.74 0.6800
20260-0300-160 3 160 276.52 0.6000
20260-0300-180 3 180 310.96 0.5300
20260-0300-200 3 200 345.87 0.4800
20260-0300-250 3 250 433.56 0.3900
20260-0300-300 3 300 517.28 0.3200
20260-0300-400 3 400 685.35 0.1600
20260-0400-060 4 60 104 2.9800
20260-0400-070 4 70 121.01 2.1200
20260-0400-080 4 80 138.1 1.8600
20260-0400-100 4 100 171.93 1.4700
20260-0400-120 4 120 207.4 1.2300
20260-0400-140 4 140 242.67 1.0500
20260-0400-160 4 160 275.6 0.9200
20260-0400-180 4 180 311.49 0.8200
20260-0400-200 4 200 345.18 0.9000
20260-0400-250 4 250 431.39 0.7200
20260-0400-300 4 300 515.33 0.6000
20260-0400-400 4 400 675.3 0.4000
20260-0500-100 5 100 170.17 2.1000
20260-0500-120 5 120 207.49 1.7500
20260-0500-140 5 140 242.67 1.5000
20260-0500-160 5 160 273.24 1.3100
20260-0500-180 5 180 309.04 1.1700
20260-0500-200 5 200 342.87 1.2800
20260-0500-250 5 250 432.98 1.0300
20260-0500-300 5 300 512.51 0.8600
20260-0500-400 5 400 688.61 0.6000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
