Rope coupling SA self-assembly

제품 라인업 — Wire ropes · Wire rope accessories

Rope coupling SA self-assembly

No.	ø	b	ø d1	F_Rd kN ETA	F_Rd kN	kg
30942-0200	2	35	5		1.1	0.0040
Further informations Diameter: 2 mm Weight: 0.0040 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30942-0300	3	55	6		2.5	0.0090
Further informations Diameter: 3 mm Weight: 0.0090 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30942-0400	4	60	7		4.4	0.0120
Further informations Diameter: 4 mm Weight: 0.0120 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30942-0500	5	75	8		6.1	0.0160
Further informations Diameter: 5 mm Weight: 0.0160 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30942-0600	6	95	10	11.6	8.7	0.0340
Further informations Diameter: 6 mm Weight: 0.0340 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30942-0800	8	150	13	16.2	17.8	0.0880
Further informations Diameter: 8 mm Weight: 0.0880 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
