GreenBlock 125 Set
No. a b1 b2 b3 ø d1 ø d2 ø d3 ø d4 kg
30805-0125-120-1 M10 120 100 70 125 90 90 170 1.5700
30805-0125-140-2 M10 140 120 74 125 90 90 170 1.7500
30805-0125-160-3 M10 160 140 74 125 90 90 170 1.9200
30805-0125-180-4 M10 180 160 79 125 90 90 170 2.1000
30805-0125-200-5 M10 200 180 84 125 90 90 170 2.2800
30805-0125-220-6 M10 220 200 94 125 90 90 170 2.4800
30805-0125-240-7 M10 240 220 99 125 90 90 170 2.6500
30805-0125-260-8 M10 260 240 104 125 90 90 170 2.8300

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
