Cross clamp

No.	ø	a	b1	b2	ø d	sw	kg
30858-0200	2	M12	18	6	20	6	0.0330
Further informations Diameter: 2 mm Weight: 0.0330 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0300	3	M12	19	6.5	20	6	0.0320
Further informations Diameter: 3 mm Weight: 0.0320 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0400	4	M12	21	7	20	6	0.0380
Further informations Diameter: 4 mm Weight: 0.0380 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0500	5	M12	23	7.5	20	6	0.0340
Further informations Diameter: 5 mm Weight: 0.0340 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0600	6	M12	25	8	20	6	0.0350
Further informations Diameter: 6 mm Weight: 0.0350 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
