Square-link pulling chain with suspension link, clevis hook and shortening hook

제품 라인업 — Chains · Chains class 10 and accessories

Square-link pulling chain with suspension link, clevis hook and shortening hook
No. ø L WLL kN kg
80262-0820-101 8 2 50 5.7000
80262-0825-101 8 2.5 50 6.7000
80262-0830-101 8 3 50 7.7000
80262-0840-101 8 4 50 9.7000
80262-0850-101 8 5 50 11.7000
80262-1020-101 10 2 80 5.4000
80262-1025-101 10 2.5 80 5.4000
80262-1030-101 10 3 80 5.4000
80262-1040-101 10 4 80 5.4000
80262-1050-101 10 5 80 5.4000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
