Web sling four-leg
No. b6 Typ L WLL_ßA kN WLL_ßB kN kg
70450-0025-015 25 GS-25-4 1.5 5.3 3.7 -
70450-0025-020 25 GS-25-4 2 5.3 3.7 -
70450-0025-025 25 GS-25-4 2.5 5.3 3.7 -
70450-0025-030 25 GS-25-4 3 5.3 3.7 -
70450-0030-015 30 GD-30-4 1.5 21 15 -
70450-0030-020 30 GD-30-4 2 21 15 -
70450-0030-025 30 GD-30-4 2.5 21 15 -
70450-0030-030 30 GD-30-4 3 21 15 -
70450-0052-015 50 GD-52-4 1.5 31.5 22.5 -
70450-0052-020 50 GD-52-4 2 31.5 22.5 -
70450-0052-025 50 GD-52-4 2.5 31.5 22.5 -
70450-0052-030 50 GD-52-4 3 31.5 22.5 -
70450-0060-015 60 GD-60-4 1.5 42 60 -
70450-0060-020 60 GD-60-4 2 42 60 -
70450-0060-025 60 GD-60-4 2.5 42 60 -
70450-0060-030 60 GD-60-4 3 42 60 -
70450-1025-015 25 GD-25-4 1.5 13 9.4 -
70450-1025-020 25 GD-25-4 2 13 9.4 -
70450-1025-025 25 GD-25-4 2.5 13 9.4 -
70450-1025-030 25 GD-25-4 3 13 9.4 -

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
