Shackle omega-type

제품 라인업 — Wire rope accessories · Connecting / tensioning

Shackle omega-type
No. b1 b2 g Inches ø d1 ø d2 ø d3 WLL kN kg
30550-0050 20 28 12 1/4" 6.5 8 17 5 0.0500
30550-0100 26 36 16 3/8" 10 11 25 10 0.1400
30550-0150 29 42 18 7/16" 11 13 27 15 0.2000
30550-0200 33 48 21 1/2" 13 16 30 20 0.3000
30550-0330 43 60 27 5/8" 16 19 40 33 0.6500
30550-0480 51 71 32 3/4" 19 22 48 48 0.9700
30550-0650 58 84 36 7/8" 22 25 54 65 1.5000
30550-0850 68 95 43 1" 25 29 60 85 2.4000
30550-0950 74 108 46 1 1/8" 29 32 67 95 3.2000
30550-1200 82 119 52 1 1/4" 32 35 76 120 4.3000
30550-1350 92 133 57 1 3/8" 35 38 84 135 5.7000
30550-1700 98 146 60 1 1/2" 38 41 92 170 7.8000
30550-2500 127 178 73 1 3/4" 44 51 110 250 12.5000
30550-3500 146 197 83 2" 51 57 127 350 18.5000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
