Shackle omega-type with nut and split pin

제품 라인업 — Wire rope accessories · Connecting / tensioning

Shackle omega-type with nut and split pin
No. b1 b2 g Inches ø d1 ø d2 ø d3 WLL kN kg
30555-0200 33 48 21 1/2" 13 16 30 20 0.4000
30555-0330 43 60 27 5/8" 16 19 40 33 0.7000
30555-0480 51 71 32 3/4" 19 22 48 48 1.3000
30555-0650 58 84 36 7/8" 22 25 54 65 1.8000
30555-0850 68 95 43 1" 25 29 60 85 2.5000
30555-0950 74 108 46 1 1/8" 29 32 67 95 3.5000
30555-1200 82 119 52 1 1/4" 32 35 76 120 5.0000
30555-1350 92 133 57 1 3/8" 35 38 84 135 6.8000
30555-1700 98 146 60 1 1/2" 38 41 92 170 8.8000
30555-2500 127 178 73 1 3/4" 44 51 110 250 14.1000
30555-3500 146 197 83 2" 51 57 127 350 20.8000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
