Threaded chain connection

제품 라인업 — Wire rope accessories · Connecting / tensioning

Threaded chain connection
No. b1 b2 g ø d WLL kN kg
30562-0400 33 10 5.5 4 1.8 0.0120
30562-0500 39 12 6.5 5 2.8 0.0210
30562-0600 45 13 7.5 6 4 0.0350
30562-0700 53 16 8.5 7 5.5 0.0570
30562-0800 59 16 10 8 7 0.0800
30562-1000 70 20 12 10 11 0.1480
30562-1200 82 22 14 12 15 0.2350
30562-1400 92 27 17 14 20 0.3540

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
