Trigger snap

제품 라인업 — Wire rope accessories · Connecting / tensioning

Trigger snap

No.	b1	b2	g	ø d1	ø d2	WLL kN	kg
30450-0055	50	4	7	5	8	0.6	0.0170
Further informations Surface: galvanized Weight: 0.0170 kg Material group: steel Price basis / tiered prices Price on request
30450-0066	60	5	8	6	9	1.2	0.0270
Further informations Surface: galvanized Weight: 0.0270 kg Material group: steel Price basis / tiered prices Price on request
30450-0077	70	8	8	7	10	1.8	0.0450
Further informations Surface: galvanized Weight: 0.0450 kg Material group: steel Price basis / tiered prices Price on request
30450-0088	80	8	9	8	11	1.8	0.0640
Further informations Surface: galvanized Weight: 0.0640 kg Material group: steel Price basis / tiered prices Price on request
30450-1010	100	10	11	10	15	2.3	0.1260
Further informations Surface: galvanized Weight: 0.1260 kg Material group: steel Price basis / tiered prices Price on request
30450-1211	120	11	16	11	18	4.5	0.1900
Further informations Surface: galvanized Weight: 0.1900 kg Material group: steel Price basis / tiered prices Price on request
30450-1412	140	13	19	12	20	5.1	0.2600
Further informations Surface: galvanized Weight: 0.2600 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
