Turnbuckle with hook/eye metrisch

제품 라인업 — Wire rope accessories · Connecting / tensioning

Turnbuckle with hook/eye metrisch

No.	b1 min	b1 max	b2	g	k1	k2	NG	ø d1	ø d2	WLL kN	kg
30260-0060-02	82	110	50	7	4	4	M5	8	18	0.4	0.0300
Further informations Standard and Classification: DIN 1480 Surface: galvanized Weight: 0.0300 kg Material group: steel Price basis / tiered prices Price on request
30260-0120-02	145	225	110	8	5	5	M6	10	19	0.6	0.1050
Further informations Standard and Classification: DIN 1480 Surface: galvanized Weight: 0.1050 kg Material group: steel Price basis / tiered prices Price on request
30260-0240-02	160	240	110	9	5	6	M8	11	22	1.2	0.1450
Further informations Standard and Classification: DIN 1480 Surface: galvanized Weight: 0.1450 kg Material group: steel Price basis / tiered prices Price on request
30260-0400-02	185	270	125	11	6	8	M10	14	28	2	0.2800
Further informations Standard and Classification: DIN 1480 Surface: galvanized Weight: 0.2800 kg Material group: steel Price basis / tiered prices Price on request
30260-0560-02	215	295	125	14	9	10	M12	15	34	2.6	0.4200
Further informations Standard and Classification: DIN 1480 Surface: galvanized Weight: 0.4200 kg Material group: steel Price basis / tiered prices Price on request
30260-0800-02	225	310	140	14	11	11	M14	18	40	4.5	0.5500
Further informations Standard and Classification: DIN 1480 Surface: galvanized Weight: 0.5500 kg Material group: steel Price basis / tiered prices Price on request
30260-1100-02	270	380	170	16	12	11	M16	22	46	5.5	1.0000
Further informations Standard and Classification: DIN 1480 Surface: galvanized Weight: 1.0000 kg Material group: steel Price basis / tiered prices Price on request
30260-1700-02	325	445	200	18	14	16	M20	25	52	8.5	1.6000
Further informations Standard and Classification: DIN 1480 Surface: galvanized Weight: 1.6000 kg Material group: steel Price basis / tiered prices Price on request
30260-2100-02	369	514	225	23	15	20	M22	29	60	10.5	2.1000
Further informations Standard and Classification: DIN 1480 Surface: galvanized Weight: 2.1000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
