Turnbuckle with two eyes metrisch

제품 라인업 — Wire rope accessories · Connecting / tensioning

Turnbuckle with two eyes metrisch
No. b1 min b1 max b2 k1 NG ø d1 ø d2 WLL kN kg
30260-0060 75 100 50 4 M5 8 18 0.6 0.0300
30260-0120 140 220 110 5 M6 10 19 1.2 0.1050
30260-0240 145 225 110 5 M8 11 22 2.4 0.1450
30260-0400 180 265 125 6 M10 14 28 4 0.2800
30260-0560 180 260 125 9 M12 15 34 5.6 0.4200
30260-0800 225 315 140 11 M14 18 40 8 0.5500
30260-1100 260 365 170 12 M16 22 46 11 1.0000
30260-1700 305 435 200 14 M20 25 52 17 1.6000
30260-2100 330 475 225 15 M22 29 60 21 2.1000
30260-2500 385 560 255 18 M24 34 65 25 2.0000
30260-4000 400 560 255 21 M30 34 83 40 3.9000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
