Turnbuckle with two hooks metrisch
No. b1 min b1 max b2 g k2 NG WLL kN kg
30260-0060-01 85 110 50 7 4 M5 0.4 0.0300
30260-0120-01 160 235 110 8 5 M6 0.6 0.1050
30260-0240-01 175 250 110 9 6 M8 1.2 0.1450
30260-0400-01 200 290 125 11 8 M10 2 0.2800
30260-0560-01 230 310 125 14 10 M12 2.6 0.4200
30260-0800-01 255 345 140 14 11 M14 4.5 0.5500
30260-1100-01 300 400 170 16 12 M16 5.5 1.0000
30260-1700-01 355 470 200 18 14 M20 8.5 1.6000
30260-2100-01 400 545 225 23 20 M22 10.5 2.1000
30260-4000-01 480 645 255 33 28 M30 20 3.9000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
