Heavy-duty thimble

제품 라인업 — Wire rope accessories · Crimping sleeves, thimbles

Heavy-duty thimble

No.	ø	b	k	ø d	kg
30140-0800	8	66	15	14	0.2000
Further informations Standard and Classification: DIN 3091 Surface: raw Diameter: 8 mm Weight: 0.2000 kg Material group: steel Price basis / tiered prices Price on request
30140-1000	10	82	17.5	18	0.3000
Further informations Standard and Classification: DIN 3091 Surface: raw Diameter: 10 mm Weight: 0.3000 kg Material group: steel Price basis / tiered prices Price on request
30140-1200	12	98	20	21	0.5000
Further informations Standard and Classification: DIN 3091 Surface: raw Diameter: 12 mm Weight: 0.5000 kg Material group: steel Price basis / tiered prices Price on request
30140-1400	14	114	23.5	25	0.8000
Further informations Standard and Classification: DIN 3091 Surface: raw Diameter: 14 mm Weight: 0.8000 kg Material group: steel Price basis / tiered prices Price on request
30140-1600	16	130	26	28	0.9000
Further informations Standard and Classification: DIN 3091 Surface: raw Diameter: 16 mm Weight: 0.9000 kg Material group: steel Price basis / tiered prices Price on request
30140-1800	18	145	28.5	31	1.2000
Further informations Standard and Classification: DIN 3091 Surface: raw Diameter: 18 mm Weight: 1.2000 kg Material group: steel Price basis / tiered prices Price on request
30140-2000	20	161	31	35	1.6000
Further informations Standard and Classification: DIN 3091 Surface: raw Diameter: 20 mm Weight: 1.6000 kg Material group: steel Price basis / tiered prices Price on request
30140-2200	22	177	33.5	38	2.1000
Further informations Standard and Classification: DIN 3091 Surface: raw Diameter: 22 mm Weight: 2.1000 kg Material group: steel Price basis / tiered prices Price on request
30140-3600	36	288	53	59	8.9000
Further informations Standard and Classification: DIN 3091 Surface: raw Diameter: 36 mm Weight: 8.9000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
