제품 라인업 — Wire rope accessories · Crimping sleeves, thimbles
| No. | ø | b | k | ø d | kg | |
|---|---|---|---|---|---|---|
| 30110-1013-1 | 10-13 | 185 | 21 | 80 | 0.5000 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||
| 30110-1417 | 14-17 | 160 | 25 | 60 | 0.7000 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||
| 30110-1820 | 18-20 | 170 | 30 | 70 | 0.9540 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||
| 30110-2200 | 22 | 170 | 32 | 75 | 1.2000 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
