Thimble cast steel

제품 라인업 — Wire rope accessories · Crimping sleeves, thimbles

Thimble cast steel

No.	ø	b	k	ø d	kg
30120-1013	10-13	72	24	25	0.5000
Further informations Surface: painted Diameter: 10-13 mm Weight: 0.5000 kg Material group: steel Price basis / tiered prices Price on request
30120-1416	14-16	120	30	32	1.2000
Further informations Surface: painted Diameter: 14-16 mm Weight: 1.2000 kg Material group: steel Price basis / tiered prices Price on request
30120-1719	17-19	120	36	37	1.0000
Further informations Surface: painted Diameter: 17-19 mm Weight: 1.0000 kg Material group: steel Price basis / tiered prices Price on request
30120-2022	20-22	153	43	44	2.3000
Further informations Surface: painted Diameter: 20-22 mm Weight: 2.3000 kg Material group: steel Price basis / tiered prices Price on request
30120-2326	23-26	153	46	52	3.0000
Further informations Surface: painted Diameter: 23-26 mm Weight: 3.0000 kg Material group: steel Price basis / tiered prices Price on request
30120-2729	27-29	185	52	57	4.0000
Further informations Surface: painted Diameter: 27-29 mm Weight: 4.0000 kg Material group: steel Price basis / tiered prices Price on request
30120-3033	30-33	185	59	63	5.0000
Further informations Surface: painted Diameter: 30-33 mm Weight: 5.0000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
