Thimble forget

제품 라인업 — Wire rope accessories · Crimping sleeves, thimbles

Thimble forget

No.	ø	b	k	ø d	kg
30101-0800	8	74	14	30	0.0750
Further informations Surface: hot-dip-galvanized Diameter: 8 mm Weight: 0.0750 kg Material group: steel Price basis / tiered prices Price on request
30101-1000	10	78	15	35	0.1050
Further informations Surface: hot-dip-galvanized Diameter: 10 mm Weight: 0.1050 kg Material group: steel Price basis / tiered prices Price on request
30101-1200	12	97	20	42	0.1900
Further informations Surface: hot-dip-galvanized Diameter: 12 mm Weight: 0.1900 kg Material group: steel Price basis / tiered prices Price on request
30101-1400	14	100	22	45	0.2100
Further informations Surface: hot-dip-galvanized Diameter: 14 mm Weight: 0.2100 kg Material group: steel Price basis / tiered prices Price on request
30101-1600	16	112	24	50	0.3000
Further informations Surface: hot-dip-galvanized Diameter: 16 mm Weight: 0.3000 kg Material group: steel Price basis / tiered prices Price on request
30101-1800	18	122	25	58	0.4000
Further informations Surface: hot-dip-galvanized Diameter: 18 mm Weight: 0.4000 kg Material group: steel Price basis / tiered prices Price on request
30101-2000	20	130	28	62	0.5600
Further informations Surface: hot-dip-galvanized Diameter: 20 mm Weight: 0.5600 kg Material group: steel Price basis / tiered prices Price on request
30101-2200	22	135	30	65	0.7600
Further informations Surface: hot-dip-galvanized Diameter: 22 mm Weight: 0.7600 kg Material group: steel Price basis / tiered prices Price on request
30101-2400	24	143	32	70	1.0000
Further informations Surface: hot-dip-galvanized Diameter: 24 mm Weight: 1.0000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
