Duplex clip

제품 라인업 — Wire rope accessories · End connections detachable

Duplex clip

No.	ø	a	b1	b2	k1	k2	kg
30240-0200	2	M4	31	12	12	5	0.0097
Further informations Surface: galvanized Diameter: 2 mm Weight: 0.0097 kg Material group: steel Price basis / tiered prices Price on request
30240-0300	3	M4	35	14	12	6	0.0141
Further informations Surface: galvanized Diameter: 3 mm Weight: 0.0141 kg Material group: steel Price basis / tiered prices Price on request
30240-0400	4	M5	41	17	17	8	0.0245
Further informations Surface: galvanized Diameter: 4 mm Weight: 0.0245 kg Material group: steel Price basis / tiered prices Price on request
30240-0500	5	M5	51	20	17	9	0.0291
Further informations Surface: galvanized Diameter: 5 mm Weight: 0.0291 kg Material group: steel Price basis / tiered prices Price on request
30240-0600	6	M6	61	24	23	10	0.0500
Further informations Surface: galvanized Diameter: 6 mm Weight: 0.0500 kg Material group: steel Price basis / tiered prices Price on request
30240-0800	8	M8	74	30	28	14	0.1063
Further informations Surface: galvanized Diameter: 8 mm Weight: 0.1063 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
