제품 라인업 — Wire rope accessories · End connections detachable
| No. | ø | a | b1 | b2 | sw | kg | |
|---|---|---|---|---|---|---|---|
| 30210-0507 | 5-7 | 3/8 | 50 | 25 | 18 | 0.0816 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||
| 30210-0800 | 8 | 3/8 | 55 | 27 | 18 | 0.1270 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||
| 30210-1000 | 10 | 7/16 | 75 | 28 | 19 | 0.1810 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||
| 30210-1113 | 11-13 | 1/2 | 85 | 32 | 22 | 0.3180 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||
| 30210-1416 | 14-16 | 5/8 | 110 | 39 | 27 | 0.4540 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||
| 30210-1820 | 18-20 | 3/4 | 115 | 47 | 32 | 0.7900 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||
| 30210-2200 | 22 | 3/4 | 120 | 56 | 32 | 1.0200 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||
| 30210-2426 | 24-26 | 3/4 | 143 | 58 | 32 | 1.3600 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||
| 30210-3234 | 32-34 | 7/8 | 170 | 66 | 36 | 1.8100 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||
| 30210-3640 | 36-40 | 1 | 220 | 80 | 41 | 3.1800 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
