Rope socket with wedge and wire rope clip

제품 라인업 — Wire rope accessories · End connections detachable

Rope socket with wedge and wire rope clip

No.	ø	b1	b2	e	f	g	ø d	kg
30280-0405	4-5	110	19	14	43	12	10	0.1700
Further informations Standard and Classification: according to EN 13411-7 Surface: hot-dip-galvanized, painted Diameter: 4-5 mm Weight: 0.1700 kg Material group: steel Price basis / tiered prices Price on request
30280-0608	6-8	150	23	20	55	14	12	0.5000
Further informations Standard and Classification: according to EN 13411-7 Surface: hot-dip-galvanized, painted Diameter: 6-8 mm Weight: 0.5000 kg Material group: steel Price basis / tiered prices Price on request
30280-0911	9-11	190	30	26	69	17	16	1.0400
Further informations Standard and Classification: according to EN 13411-7 Surface: hot-dip-galvanized, painted Diameter: 9-11 mm Weight: 1.0400 kg Material group: steel Price basis / tiered prices Price on request
30280-1214	12-14	230	40	33	84	22	18	2.0700
Further informations Standard and Classification: according to EN 13411-7 Surface: hot-dip-galvanized, painted Diameter: 12-14 mm Weight: 2.0700 kg Material group: steel Price basis / tiered prices Price on request
30280-1517	15-17	260	48	36	94	25	22	3.6600
Further informations Standard and Classification: according to EN 13411-7 Surface: hot-dip-galvanized, painted Diameter: 15-17 mm Weight: 3.6600 kg Material group: steel Price basis / tiered prices Price on request
30280-1820	18-20	300	53	39	111	27	25	5.3500
Further informations Standard and Classification: according to EN 13411-7 Surface: hot-dip-galvanized, painted Diameter: 18-20 mm Weight: 5.3500 kg Material group: steel Price basis / tiered prices Price on request
30280-2225	22-25	284	60	41	128	33	42	6.2200
Further informations Standard and Classification: according to EN 13411-7 Surface: hot-dip-galvanized, painted Diameter: 22-25 mm Weight: 6.2200 kg Material group: steel Price basis / tiered prices Price on request
30280-2630	26-30	335	87	56	149	40	52	10.1000
Further informations Standard and Classification: according to EN 13411-7 Surface: hot-dip-galvanized, painted Diameter: 26-30 mm Weight: 10.1000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
