Rope socket with wedge and wire rope clip short, heavy design

제품 라인업 — Wire rope accessories · End connections detachable

Rope socket with wedge and wire rope clip short, heavy design
No. ø b1 e f g ø d kg
30290-0507 5-7 118 12 25 13.5 12 0.6000
30290-0809 8-9 118 17 25 13.5 12 0.7500
30290-1011 10-11 118 17 25 13.5 12 0.7500
30290-1112 11-12 145 30 38 23 20 1.8000
30290-1300 13 145 30 38 23 20 1.8000
30290-1400 14 145 30 38 23 20 1.8000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
