Securite clip with 2 bolts

제품 라인업 — Wire rope accessories · End connections detachable

Securite clip with 2 bolts

No.	ø	a	b1	b2	b3	k	kg
30220-0406	6	M6	18	34	33	27	0.0800
Further informations Surface: body hot-dip-galvanized, bolts galvanized Diameter: 6 mm Weight: 0.0800 kg Material group: steel Price basis / tiered prices Price on request
30220-0709	9	M8	24	46	36	32	0.1400
Further informations Surface: body hot-dip-galvanized, bolts galvanized Diameter: 9 mm Weight: 0.1400 kg Material group: steel Price basis / tiered prices Price on request
30220-0913	12	M10	30	56	47	40	0.2900
Further informations Surface: body hot-dip-galvanized, bolts galvanized Diameter: 12 mm Weight: 0.2900 kg Material group: steel Price basis / tiered prices Price on request
30220-1415	16	M12	35	67	55	47	0.4400
Further informations Surface: body hot-dip-galvanized, bolts galvanized Diameter: 16 mm Weight: 0.4400 kg Material group: steel Price basis / tiered prices Price on request
30220-1619	20	M14	46	89	63	54	0.7900
Further informations Surface: body hot-dip-galvanized, bolts galvanized Diameter: 20 mm Weight: 0.7900 kg Material group: steel Price basis / tiered prices Price on request
30220-2026	25	M16	51	110	72	69	1.3000
Further informations Surface: body hot-dip-galvanized, bolts galvanized Diameter: 25 mm Weight: 1.3000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
