Wedge socket S-421T

제품 라인업 — Wire rope accessories · End connections detachable

Wedge socket S-421T

No.	ø	b1	b2	e	f	g	Inches	k	ø d1	ø d2	kg
30300-0910	9-10	143	29	22	65	20	3/8"	11	41	21	1.0000
Further informations Surface: painted Diameter: 9-10 mm Weight: 1.0000 kg Material group: steel Price basis / tiered prices Price on request
30300-1113	11-13	173	35	27	68	25	1/2"	13	51	26	2.0000
Further informations Surface: painted Diameter: 11-13 mm Weight: 2.0000 kg Material group: steel Price basis / tiered prices Price on request
30300-1416	14-16	202	45	31	85	31	5/8"	14	58	31	4.0000
Further informations Surface: painted Diameter: 14-16 mm Weight: 4.0000 kg Material group: steel Price basis / tiered prices Price on request
30300-1719	17-19	245	52	36	90	38	3/4"	17	67	36	6.0000
Further informations Surface: painted Diameter: 17-19 mm Weight: 6.0000 kg Material group: steel Price basis / tiered prices Price on request
30300-2022	20-22	283	59	42	110	44	7/8"	19	79	42	10.0000
Further informations Surface: painted Diameter: 20-22 mm Weight: 10.0000 kg Material group: steel Price basis / tiered prices Price on request
30300-2326	23-26	324	65	51	123	50	1"	22	94	51	15.0000
Further informations Surface: painted Diameter: 23-26 mm Weight: 15.0000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
