Wire rope clamp Eureka

제품 라인업 — Wire rope accessories · End connections detachable

Wire rope clamp Eureka

No.	ø	a	b1	b2	k	kg
30250-0800	8	M6	42	28	28	0.1450
Further informations Tightening torque: tightening torque 18.0 Nm Surface: hot-dip-galvanized Diameter: 8 mm Weight: 0.1450 kg Material group: steel Price basis / tiered prices Price on request
30250-0910	9-10	M8	61	42	42	0.5500
Further informations Tightening torque: tightening torque 30.0 Nm Surface: hot-dip-galvanized Diameter: 9-10 mm Weight: 0.5500 kg Material group: steel Price basis / tiered prices Price on request
30250-1100	11	M8	61	42	42	0.5000
Further informations Tightening torque: tightening torque 30.0 Nm Surface: hot-dip-galvanized Diameter: 11 mm Weight: 0.5000 kg Material group: steel Price basis / tiered prices Price on request
30250-1213	12-13	M10	80	46	46	0.7750
Further informations Tightening torque: tightening torque 70.0 Nm Surface: hot-dip-galvanized Diameter: 12-13 mm Weight: 0.7750 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
