Wire rope clamp oval

제품 라인업 — Wire rope accessories · End connections detachable

Wire rope clamp oval

No.	ø	a	b1	b2	k	kg
30205-0200	2	M5	28	15	11	0.0020
Further informations Surface: galvanized Diameter: 2 mm Weight: 0.0020 kg Material group: steel Price basis / tiered prices Price on request
30205-0300	3	M5	28	15	12	0.0021
Further informations Surface: galvanized Diameter: 3 mm Weight: 0.0021 kg Material group: steel Price basis / tiered prices Price on request
30205-0400	4	M6	34	20	14	0.0039
Further informations Surface: galvanized Diameter: 4 mm Weight: 0.0039 kg Material group: steel Price basis / tiered prices Price on request
30205-0500	5	M6	34	21	15	0.0040
Further informations Surface: galvanized Diameter: 5 mm Weight: 0.0040 kg Material group: steel Price basis / tiered prices Price on request
30205-0600	6	M6	35	25	15	0.0048
Further informations Surface: galvanized Diameter: 6 mm Weight: 0.0048 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
