Eye slip hook with latch

제품 라인업 — Wire rope accessories · Lifting accessories

Eye slip hook with latch

No.	b1	b2	g	lx	NG	ø d1	ø d2	WLL kN	kg
30470-0110	114	86	21	11	6	20	8	11	0.2300
Further informations Surface: painted Weight: 0.2300 kg Material group: steel Price basis / tiered prices Price on request
30470-0200	156	118	27	20	7-8	28	11	20	0.5900
Further informations Surface: painted Weight: 0.5900 kg Material group: steel Price basis / tiered prices Price on request
30470-0320	200	158	36	32	10	36	14	32	1.1800
Further informations Surface: painted Weight: 1.1800 kg Material group: steel Price basis / tiered prices Price on request
30470-0540	243	184	39	54	13	46	18	54	2.1100
Further informations Surface: painted Weight: 2.1100 kg Material group: steel Price basis / tiered prices Price on request
30470-0800	301	227	49	80	16	56	22	80	3.8800
Further informations Surface: painted Weight: 3.8800 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
