Hoist hook drop-forged

제품 라인업 — Wire rope accessories · Lifting accessories

Hoist hook drop-forged

No.	b1	b2	g	ø d1	ø d2	WLL kN	kg
30490-0080	113	85	23	19	9	7.5	0.3000
Further informations Surface: painted Weight: 0.3000 kg Material group: steel Price basis / tiered prices Price on request
30490-0100	129	97	24	23	11	10	0.4000
Further informations Surface: painted Weight: 0.4000 kg Material group: steel Price basis / tiered prices Price on request
30490-0160	146	108	25	29	14	16	0.7000
Further informations Surface: painted Weight: 0.7000 kg Material group: steel Price basis / tiered prices Price on request
30490-0200	166	122	29	32	15	20	1.0000
Further informations Surface: painted Weight: 1.0000 kg Material group: steel Price basis / tiered prices Price on request
30490-0320	205	150	37	40	18	32	1.9000
Further informations Surface: painted Weight: 1.9000 kg Material group: steel Price basis / tiered prices Price on request
30490-0500	262	193	44	51	23	50	4.0000
Further informations Surface: painted Weight: 4.0000 kg Material group: steel Price basis / tiered prices Price on request
30490-0750	321	236	58	62	28	75	7.0000
Further informations Surface: painted Weight: 7.0000 kg Material group: steel Price basis / tiered prices Price on request
30490-1000	359	261	63	72	39	100	10.0000
Further informations Surface: painted Weight: 10.0000 kg Material group: steel Price basis / tiered prices Price on request
30490-1500	445	329	84	89	44	150	18.0000
Further informations Surface: painted Weight: 18.0000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
