| No. | b1 | b2 | b3 | g | k1 | k2 | WLL kN | kg | |
|---|---|---|---|---|---|---|---|---|---|
| 30401-0200-04 | 310 | 24 | 50 | 34 | 15 | 20 | 20 | 1.8260 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30401-0315-04 | 374 | 30 | 65 | 44 | 19 | 26 | 31.5 | 3.4090 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30401-0530-04 | 471 | 39 | 72 | 55 | 23 | 30 | 53 | 6.8390 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30401-0800-04 | 560 | 49 | 80 | 60 | 25 | 36 | 80 | 11.5260 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30401-1250-04 | 624 | 42 | 104 | 90 | 31 | 48 | 125 | 16.0420 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
