Master link assembly electrically welded
No. b1 b2 b3 b4 ø d1 ø d2 WLL kN kg
30385-0200 130 65 80 45 16 13 20 1.3000
30385-0320 140 75 90 50 18 13 32 1.6000
30385-0400 180 90 105 55 22 16 40 2.9000
30385-0500 180 90 110 60 22 18 50 3.3000
30385-0630 200 100 125 65 26 18 63 4.5000
30385-0800 200 100 125 70 26 20 80 4.9000
30385-1000 230 115 145 80 32 22 100 7.8000
30385-1250 250 130 150 90 36 26 125 11.1000
30385-1500 260 140 160 95 36 26 150 11.7000
30385-2000 350 180 200 110 51 40 200 32.0000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
