Reevable link electrically welded
No. b1 b2 ø d WLL kN kg
30390-0100 115 65 13 14 0.4000
30390-0200 130 65 16 20 0.6800
30390-0300 140 75 18 32 0.9500
30390-0400 180 90 20 40 1.4500
30390-0550 180 90 22 50 1.8000
30390-0650 200 100 23 63 2.1500
30390-0700 200 100 26 70 2.7500
30390-0800 230 115 28 80 3.7000
30390-1000 230 115 32 100 4.8000
30390-1250 250 125 36 125 6.6000
30390-1400 280 150 36 140 7.5500
30390-1750 280 150 40 175 9.3500

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
