Safety hook type CLS/YC

제품 라인업 — Wire rope accessories · Lifting accessories

Safety hook type CLS/YC

No.	b1	b2	g	ø d1	ø d2	WLL kN	kg
30480-0100-10	139	110	28	21	10	14	0.5000
Further informations Surface: painted Weight: 0.5000 kg Material group: steel Nominal strength (Mat. strength): class 10 Price basis / tiered prices Price on request
30480-0200-10	171	136	34	25	11	25	0.8000
Further informations Surface: painted Weight: 0.8000 kg Material group: steel Nominal strength (Mat. strength): class 10 Price basis / tiered prices Price on request
30480-0320-10	210	167	44	32	13	40	1.5000
Further informations Surface: painted Weight: 1.5000 kg Material group: steel Nominal strength (Mat. strength): class 10 Price basis / tiered prices Price on request
30480-0500-10	262	207	51	40	16	67	3.0000
Further informations Surface: painted Weight: 3.0000 kg Material group: steel Nominal strength (Mat. strength): class 10 Price basis / tiered prices Price on request
30480-0800-10	322	252	60	50	21	100	5.8000
Further informations Surface: painted Weight: 5.8000 kg Material group: steel Nominal strength (Mat. strength): class 10 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
