SIKA-snap hook with stable latch

제품 라인업 — Wire rope accessories · Lifting accessories

SIKA-snap hook with stable latch

No.	b1	b2	g	ø d1	ø d2	WLL kN	kg
30460-0050	130	93	20	25	10	5	0.5000
Further informations Surface: painted Weight: 0.5000 kg Material group: steel Price basis / tiered prices Price on request
30460-0100	147	105	24	27	13	10	0.8000
Further informations Surface: painted Weight: 0.8000 kg Material group: steel Price basis / tiered prices Price on request
30460-0160	160	115	28	28	14	16	1.0000
Further informations Surface: painted Weight: 1.0000 kg Material group: steel Price basis / tiered prices Price on request
30460-0200	169	123	29	32	14	20	1.1000
Further informations Surface: painted Weight: 1.1000 kg Material group: steel Price basis / tiered prices Price on request
30460-0320	195	138	34	34	17	32	1.6000
Further informations Surface: painted Weight: 1.6000 kg Material group: steel Price basis / tiered prices Price on request
30460-0500	255	188	45	50	23	50	3.6000
Further informations Surface: painted Weight: 3.6000 kg Material group: steel Price basis / tiered prices Price on request
30460-0800	299	216	57	54	26	80	5.4000
Further informations Surface: painted Weight: 5.4000 kg Material group: steel Price basis / tiered prices Price on request
30460-1000	329	234	61	60	34	100	8.1000
Further informations Surface: painted Weight: 8.1000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
