Swivel hook with safety latch

제품 라인업 — Wire rope accessories · Lifting accessories

Swivel hook with safety latch

No.	b1	b2	g	ø d1	ø d2	WLL kN	kg
30410-0100	169	134	24	37	13	10	0.6000
Further informations Surface: painted Weight: 0.6000 kg Material group: steel Price basis / tiered prices Price on request
30410-0200	206	162	28	43	16	20	1.2000
Further informations Surface: painted Weight: 1.2000 kg Material group: steel Price basis / tiered prices Price on request
30410-0300	244	188	27	50	19	30	2.2000
Further informations Surface: painted Weight: 2.2000 kg Material group: steel Price basis / tiered prices Price on request
30410-0500	315	244	38	62	25	50	4.7000
Further informations Surface: painted Weight: 4.7000 kg Material group: steel Price basis / tiered prices Price on request
30410-0750	368	282	44	69	28	75	7.4000
Further informations Surface: painted Weight: 7.4000 kg Material group: steel Price basis / tiered prices Price on request
30410-1000	403	306	48	78	31	100	10.7000
Further informations Surface: painted Weight: 10.7000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
