Lifting point with short screw

제품 라인업 — Wire rope accessories · Miscellaneous

Lifting point with short screw

No.	b1	b2	b4	b5	c	NG	ø d	WLL kN	kg
80362-0025	75	40	35	30	11	M8	10	3	0.2000
Further informations Surface: painted Weight: 0.2000 kg Material group: steel Price basis / tiered prices Price on request
80362-0050	75	39	35	30	16	M10	10	6.3	0.3000
Further informations Surface: painted Weight: 0.3000 kg Material group: steel Price basis / tiered prices Price on request
80362-0075	84	40	37	33	18	M12	10	10	0.5000
Further informations Surface: painted Weight: 0.5000 kg Material group: steel Price basis / tiered prices Price on request
80362-0100	84	38	37	33	24	M16	10	15	0.5000
Further informations Surface: painted Weight: 0.5000 kg Material group: steel Price basis / tiered prices Price on request
80362-0200	123	66	54	50	30	M20	14	25	1.3000
Further informations Surface: painted Weight: 1.3000 kg Material group: steel Price basis / tiered prices Price on request
80362-0300	123	64	54	50	36	M24	17	40	1.4000
Further informations Surface: painted Weight: 1.4000 kg Material group: steel Price basis / tiered prices Price on request
80362-0500	147	66	65	60	48	M30	23	50	3.1000
Further informations Surface: painted Weight: 3.1000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
