Sliding choker hook with safety latch

제품 라인업 — Wire rope accessories · Miscellaneous

Sliding choker hook with safety latch

No.	ø	b1	b2	g	ø d	WLL kN	kg
30430-0913	9-13	128	70	19	17	12.5	0.7000
Further informations Surface: painted Diameter: 9-13 mm Weight: 0.7000 kg Material group: steel Price basis / tiered prices Price on request
30430-1416	14-16	147	80	22	22	20	1.0000
Further informations Surface: painted Diameter: 14-16 mm Weight: 1.0000 kg Material group: steel Price basis / tiered prices Price on request
30430-1720	17-20	174	103	30	27	30	1.8000
Further informations Surface: painted Diameter: 17-20 mm Weight: 1.8000 kg Material group: steel Price basis / tiered prices Price on request
30430-2226	22-26	210	133	40	33	50	3.4000
Further informations Surface: painted Diameter: 22-26 mm Weight: 3.4000 kg Material group: steel Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
