제품 라인업 — Wire rope accessories · Non detachable end connections
| No. | ø | b1 | b2 | e | h | k | ø d1 | ø d2 | kg | |
|---|---|---|---|---|---|---|---|---|---|---|
| 30520-0600 | 6 | 109 | 54 | 20 | 35 | 13 | 13 | 19 | 0.1700 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30520-0800 | 8 | 138 | 81 | 24 | 41 | 17 | 20 | 22 | 0.3500 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30520-0910 | 9-10 | 138 | 81 | 24 | 41 | 17 | 20 | 22 | 0.3300 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30520-1112 | 11-12 | 175 | 105 | 30 | 51 | 22 | 25 | 27 | 0.6400 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30520-1300 | 13 | 175 | 107 | 30 | 51 | 21 | 25 | 27 | 0.6400 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30520-1400 | 14 | 219 | 134 | 36 | 60 | 29 | 32 | 32 | 1.3200 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30520-1600 | 16 | 219 | 134 | 36 | 60 | 29 | 32 | 32 | 1.2900 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30520-1820 | 18-20 | 261 | 162 | 42 | 73 | 33 | 39 | 37 | 2.2700 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
