Spelter socket with clevis and pin

제품 라인업 — Wire rope accessories · Non detachable end connections

Spelter socket with clevis and pin
No. ø b1 b2 b3 b4 e f g ø d kg
30530-0607 6-7 116 33 57 40 20 40 17 18 0.5000
30530-0810 8-10 124 40 59 43 20 45 20 21 0.5900
30530-1113 11-13 142 50 64 49 27 51 25 26 1.0200
30530-1416 14-16 171 58 76 60 31 63 32 30 1.8100
30530-1800 18 205 70 89 70 40 76 38 36 2.6400
30530-2022 20-22 235 80 101 82 45 89 44 42 4.4700
30530-2426 24-26 275 104 95 91 60 101 51 52 7.0300
30530-2830 28-30 298 105 125 102 63 114 57 57 9.7500
30530-3235 32-35 333 121 138 116 70 127 64 64 14.1000
30530-3800 38 384 137 152 133 75 152 76 70 21.4000
30530-4042 40-42 413 146 165 140 80 165 76 76 24.4000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
