Double loop with hoist hook swaged

제품 라인업 — Wire ropes assemblies · Double loop

Double loop with hoist hook swaged
No. ø L WLL kN kg
20271-0800-030 8 0.3 12.75 1.0600
20271-0800-060 8 0.6 12.75 1.1000
20271-1100-040 11 0.4 24.51 2.5000
20271-1100-080 11 0.8 24.51 2.7000
20271-1600-060 16 0.6 50.98 8.3000
20271-1600-120 16 1.2 50.98 9.4000
20271-2000-075 20 0.75 83.33 12.9000
20271-2000-150 20 1.5 83.33 15.2000
20271-2400-090 24 0.9 121 22.4000
20271-2400-180 24 1.8 121 26.4000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
