Double loop without hoist hook swaged

제품 라인업 — Wire ropes assemblies · Double loop

Double loop without hoist hook swaged
No. ø L WLL kN kg
20272-0800-025 8 0.25 12.75 0.3600
20272-0800-050 8 0.5 12.75 0.4400
20272-1100-030 11 0.3 24.51 0.6000
20272-1100-060 11 0.6 24.51 0.8000
20272-1600-045 16 0.9 50.98 1.3000
20272-1600-090 16 0.9 50.98 2.4000
20272-2000-060 20 0.6 83.33 2.9000
20272-2000-120 20 1.2 83.33 5.2000
20272-2400-070 24 0.7 121 4.4000
20272-2400-140 24 1.4 121 8.4000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
