Endless cable-laid grommet

제품 라인업 — Wire ropes assemblies · Endless cable-laid grommets

Endless cable-laid grommet
No. ø L WLL kN kg
20113-0600-010 6 0.5 5.6 -
20113-0600-020 6 1 5.6 -
20113-0600-030 6 1.5 5.6 -
20113-0600-040 6 2 5.6 -
20113-0600-050 6 2.5 5.6 -
20113-0900-010 9 0.5 12.6 -
20113-0900-020 9 1 12.6 0.4700
20113-0900-030 9 1.5 12.6 0.7000
20113-0900-040 9 2 12.6 0.9300
20113-0900-050 9 2.5 12.6 -
20113-1200-010 12 0.5 22.45 -
20113-1200-020 12 1 22.45 0.8300
20113-1200-030 12 1.5 22.45 -
20113-1200-040 12 2 22.45 1.6600
20113-1200-050 12 2.5 22.45 -
20113-1500-010 15 0.5 35.2 -
20113-1500-020 15 1 35.2 1.3000
20113-1500-030 15 1.5 35.2 1.9500
20113-1500-040 15 2 35.2 -
20113-1500-050 15 2.5 35.2 -
20113-1800-010 18 0.5 50.3 -
20113-1800-020 18 1 50.3 -
20113-1800-030 18 1.5 50.3 -
20113-1800-040 18 2 50.3 3.7400
20113-1800-050 18 2.5 50.3 -
20113-2100-020 21 1 68.43 -
20113-2100-030 21 1.5 68.43 -
20113-2100-040 21 2 68.43 -
20113-2100-050 21 2.5 68.43 -
20113-2400-020 24 1 89.41 -
20113-2400-030 24 1.5 89.41 -
20113-2400-040 24 2 89.41 -
20113-2400-050 24 2.5 89.41 -
20113-2700-020 27 1 113 -
20113-2700-030 27 1.5 113 -
20113-2700-040 27 2 113 -
20113-2700-050 27 2.5 113 -
20113-3000-020 30 1 140 -
20113-3000-030 30 1.5 140 -
20113-3000-040 30 2 140 -
20113-3000-050 30 2.5 140 -
20113-3300-020 33 1 169 -
20113-3300-030 33 1.5 169 -
20113-3300-040 33 2 169 -
20113-3300-050 33 2.5 169 -
20113-3600-030 36 1.5 201 -
20113-3600-040 36 2 201 -
20113-3600-050 36 2.5 201 -
20113-3900-030 39 1.5 235 -
20113-3900-040 39 2 235 -
20113-3900-050 39 2.5 235 -

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
