Loop with aluminium sleeve swaged

제품 라인업 — Wire ropes assemblies · Loops

Loop with aluminium sleeve swaged

No.	ø	b1	ø d2	ø d3	s	kg
20601-0600-01	6	150	variabel	12	90	0.0200
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 6 mm Weight: 0.0200 kg Price basis / tiered prices Price on request
20601-0800-01	8	180	variabel	16	120	0.0200
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 8 mm Weight: 0.0200 kg Price basis / tiered prices Price on request
20601-1000-01	10	200	variabel	20	150	0.0200
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 10 mm Weight: 0.0200 kg Price basis / tiered prices Price on request
20601-1200-01	12	220	variabel	24	180	0.0200
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 12 mm Weight: 0.0200 kg Price basis / tiered prices Price on request
20601-1300-01	13	250	variabel	26	195	0.0200
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 13 mm Weight: 0.0200 kg Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
