Loop with copper sleeve swaged without thimble

제품 라인업 — Wire ropes assemblies · Loops

Loop with copper sleeve swaged without thimble

No.	ø	b1	ø d1	ø d3	kg
20805-0200	2	10	variabel	4	0.0020
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 2 mm Weight: 0.0020 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20805-0400	4	18	variabel	8	0.0120
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 4 mm Weight: 0.0120 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20805-0500	5	23	variabel	10	0.0180
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 5 mm Weight: 0.0180 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20805-0600	6	27	variabel	12	0.0200
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 6 mm Weight: 0.0200 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20805-0800	8	36	variabel	16	0.0400
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 8 mm Weight: 0.0400 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20805-1000	10	45	variabel	20	0.0710
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 10 mm Weight: 0.0710 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20805-1200	12	54	variabel	24	0.1100
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 12 mm Weight: 0.1100 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20805-1600	16	72	variabel	32	0.2920
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 16 mm Weight: 0.2920 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
