Loop with shrink-on tube spliced

제품 라인업 — Wire ropes assemblies · Loops

Loop with shrink-on tube spliced

No.	ø	b3	ø d1	ø d5	s	kg
20701-0200	2	32	variabel	4	30	-
Further informations Standard and Classification: in compliance with EN 13411-2 Diameter: 2 mm Price basis / tiered prices Price on request
20701-0300	3	48	variabel	6	45	-
Further informations Standard and Classification: in compliance with EN 13411-2 Diameter: 3 mm Price basis / tiered prices Price on request
20701-0600	6	96	variabel	12	90	-
Further informations Standard and Classification: in compliance with EN 13411-2 Diameter: 6 mm Price basis / tiered prices Price on request
20701-0800	8	160	variabel	16	120	-
Further informations Standard and Classification: in compliance with EN 13411-2 Diameter: 8 mm Price basis / tiered prices Price on request
20701-1000	10	192	variabel	20	150	-
Further informations Standard and Classification: in compliance with EN 13411-2 Diameter: 10 mm Price basis / tiered prices Price on request
20701-1200	12	224	variabel	24	180	-
Further informations Standard and Classification: in compliance with EN 13411-2 Diameter: 12 mm Price basis / tiered prices Price on request
20701-1400	14	224	variabel	28	210	-
Further informations Standard and Classification: in compliance with EN 13411-2 Diameter: 14 mm Price basis / tiered prices Price on request
20701-1600	16	256	variabel	32	240	-
Further informations Standard and Classification: in compliance with EN 13411-2 Diameter: 16 mm Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
